Tianjin Dongli Sinopharm Holdings 900㎡ Pharmaceutical Cold Storage
Project Overview
Jinzhao Yuan Refrigeration designed and delivered a precision 900㎡ pharmaceutical cold storage facility for Sinopharm Holdings in Tianjin’s Dongli District, providing GDP-compliant temperature-controlled storage for pharmaceutical distribution operations.
Project Background
This project serves as a regional pharmaceutical distribution node for Sinopharm Holdings in the Tianjin Dongli industrial zone. The facility required compact yet fully compliant cold chain infrastructure to support the distribution of temperature-sensitive medicines, vaccines, and biopharmaceuticals to hospitals and clinics across the Tianjin-Hebei region.
Solution & Technical Highlights
- Facility Type: Pharmaceutical Cold Chain Warehouse (GDP compliant)
- Total Area: 900 ㎡
- Temperature Zones:
- Cold Zone: 2°C ~ 8°C (vaccines, biological products, special medicines)
- Cool Zone: 15°C ~ 25°C (general temperature-sensitive pharmaceuticals)
- Refrigeration System: Redundant dual scroll compressor units with automatic standby switchover; R134a refrigerant (zero ODP)
- Insulation: 150mm PU panels, stainless steel internal finish
- Monitoring:
- Wireless multi-point temperature/humidity sensors (60+ monitoring points)
- Continuous data recording system (CFDA-compliant, data retention ≥5 years)
- Triple-level alarm: on-site audible/visual, SMS notification, platform alert
- Emergency power backup: UPS with minimum 4-hour power supply
- Access Control: Pharmaceutical-grade security system with access logging for regulatory compliance
Regulatory Compliance
- China NMPA GDP certification
- CFDA cold chain management system requirements
- Tianjin Municipal Pharmaceutical Administration standards
Results
- GDP certification obtained within 30 days of commissioning
- Supports distribution of over 200 SKUs of temperature-sensitive pharmaceuticals
- Zero temperature excursion events in first 24 months of operation
- Recognized as a benchmark pharmaceutical cold chain facility within the Sinopharm Tianjin network
